2. Dielectric Strength: 1000V AC(50-60Hz) 0.5mA 1min

3 .Contact Resistance: 30mohm Max

Mechanical

1. Retention Strength: Between plug and jack 7.79kg Min

2 .Mating and un-mating force: 2.27kg Max

3 .Durability: 750 mating cycles Min.

Material

1 . Housing: Polycarbonate (PC) UL 94V-0 or UL 94V-2

2 .Contacts: Phosphor bronze, Nickel plating followed with gold plating: 3u, 6u, 15u, 30u, or 50u micro-inch selectable

Ratings

1.Current Rating: 1.5AMPS

2. Voltage Rating: 125V AC

3. Operation Working Temperature Range: -40°C~80°C

4. Preservation Range: -20~50C RH<65%
